Copper Tube Epoxy Resin Fin Air Dry Coolers Power Plant Radiator

Ask Lasest Price
Brand Name :	Shenglin
Model Number :	SHSL-D2 Series
Certification :	CE and RoHs
Price :	5999~50000 USD per unit
Payment Terms :	T/T, Western Union
Supply Ability :	100 units per month
Delivery Time :	30~35days

Add to Cart

Product Details
Company Profile

Copper Tube Epoxy Resin Fin Air Dry Coolers Power Plant Radiator

Copper Tube PowerPlant Radiator Cooler

Features

Our range of Dry Air Coolers and Radiators are designed for commercial and industrial fluid cooling applications. We offer a wide range of options enabling us to provide the most cost-effective solution for your cooling requirement.

Standard arrangements include flat-bed vertical or horizontal airflow with V configurations to offer the smallest footprint.
Whether your application is cooling water / glycol for water cooled chillers, injection moulding machines, furnace equipment, CHP Engine Cooling or any other process. One or more of our units can be selected to give the most cost-effective solution to suit your space and noise requirement.
Energy saving free cooling is possible for much of the year for many applications.

Application:
Application of dry cooler in cooling diesel generator set:

Cooling method: The water in the dry cooler system uses a heat exchanger to cool the circulating water or oil inside the generator.

Reference

For solar industry	Country: China Application :cooling of solar heating system when it is overheated Cooling capacity: 463, 933 and 1475kW Cooling medium: 50% propylene glycol water Supply power: 380V/3P/50Hz Fan brand: Ziehl-Abegg Altitude:4200m	Country: UAE Application: solar thermal system Cooling capacity: 21kw Cooling medium: water Supply power: 230V/1P/50Hz Fan brand: Chinese brand	Country: Korea Application: solar system overheated Cooling capacity: 32kW Cooling medium: 30% ethylene glycol water Supply power: 230V/1P/60Hz Fan brand: Chinese brand
For solar industry
For plastic industry	Country: Algeria Application: cooling water from injection molding machine Cooling capacity: 694kW Cooling medium: water Supply power: 400V/3P/50Hz Fan brand: Ziehl-Abegg	Country: Armenia Application: for plastic caps of beverages factory Cooling capacity:70kW Cooling medium: 34% ethylene glycol Supply power: 380V/3P/50Hz Fan brand: Chinese brand	Country: Russia Application: bathtub factory Inlet/outlet air temperature:40℃/66℃ Inlet/outlet water temperature:85℃/50℃ Air volume:7986m3/h Cooling medium:water Supply power: 380V/3P/50Hz Fan brand: Chinese brand
For plastic industry
Instead of cooling tower	Country: Argentina Application: for equipment cooling, to match chiller. Cooling capacity: 245kW Cooling medium: water Supply power:380V/3P/50Hz Fan brand: Chinese brand	Country: Peru Application: instead of cooling tower, to match chiller. Cooling capacity: 360kW Cooling medium: water Supply power:440V/3P/60Hz Fan brand: Chinese brand With wet curtain, with water pump and water tank	Country: Mauritius Application: supermarket and will match chiller use. Heat transfer capacity: 502kW Cooling medium: water Inlet air temp.: 32℃ Inlet medium temp.: 42℃ Outlet medium temp.: 37℃ Medium volume: 88m3/h Material: copper tube aluminum fin and galvanized steel frame, RAL9010 powder coating. Supply power: 380V/3P/50Hz Fan brand: Chinese brand, air volume: 20228m3/h
Instead of cooling tower
For data center cooling	Country: Mongolia Application: match with precision air conditioner Cooling capacity: 17.6kW Cooling medium: 34% ethylene glycol Supply power: 400V/3P/50Hz Fan brand: Ziehl-Abegg	Country: Russia Application:data center cooling Cooling capacity: 763kW Cooling medium: water Supply power: 380V/3P/50Hz Fan brand: Ziehl-Abegg
For data center cooling
Factory cooling	Country: Russia Application: ore yard cooling Cooling capacity: 493kW Cooling medium: 20% ethylene glycol Supply power: 400V/3P/50Hz Fan brand: Ziehl-Abegg	Country: China Application: plant cooling Cooling capacity: 52kW Cooling medium: 30% ethylene glycol Supply power: 380V/3P/50Hz Fan brand: Chinese brand
Factory cooling
For power plant	Country: Hongkong Application: power plant Cooling capacity: 363kW Cooling medium: water Supply power: 415V/3P/50Hz Fan brand: Chinese brand	Country: Russia Application: power plant. Cooling capacity: 180kW Cooling medium: water Supply power: 380V/3P/50Hz Fan brand: Chinese brand
For power plant
Other application	Country: Singapore Application: match with fruit and vegerable freezer Cooling capacity: 14.6kw, 17kw and 29.37kw Cooling medium: 20% ethylene glycol Supply power: 230V/1P/50Hz Fan brand: Ziehl-Abegg	Country: Singapore Application: wastewater treatment factory, cooling water Cooling capacity: 429kW Cooling medium: water Supply power: 400V/3P/50Hz Fan brand: Ziehl-Abegg	Country: Russia Application: industrial cooling Cooling capacity: 153kW Cooling medium: 20% glycol Supply power: 380V/3P/50Hz Fan brand: Ziehl-Abegg
Other application
